|Name:||Water cooled hot press machine|
|Control:||PLC touch screen|
|Operation:||One button type|
|Structure:||Enforced aliuminum alloy|
Whole automatic process：
Press the button Auto-Start→Pressure the start button-pressure goes up→Temp goes up
→ Temp holding period of time for welding at setting Temp → Auto-cooling and pressure
release→ Finish Indicator sounds.
Information for operation:
Temperature growing from 0 to 170 degrees takes 16min (without interval during the process).
Cooling from 170 to 60 degrees takes 4min. Temp difference between upper heating plate and
lower heating plate 3degrees.
The tolerance between the real temp and target temp 2degrees.
1) SMART SYSTEM TO REMAIN THE PRESSURE NEEDED.
2) SMART PLC SYETEM FOR TEMP CONTROLLING.
Four stages for temp setting to meet the requirement of different types of belt jointing. Functional
especially for thick belts.
